Mining Machine Drilling Machine Reducing The Labor Intensity

Overview

Basic Info.

Trademark	Jikai
Origin	Shijiazhuang City, Hebei Province, China
Production Capacity	10000sets/Year

Product Description

Product Description

MQTB-70/1.7 pneumatic propleg rib bolter, combined with drilling, mixing and fixing, is applicable for roof bolting in coal tunnel, half-coal tunnel and rock tunnel with rock hardness no more than 60MPa. This machine features high rotary speed, large torque, easy operation and maintenance. It reduces the labor intensity a lot with leg support and auxiliary support and is a good substitution for electric coal drill.

Product Parameters

Detail		Value
MainParameters	Applicable Air Pressure (MPa)	0.4-0.63
	Rated Air Pressure (MPa)	0.5
	Flushing Water Pressure (MPa)	0.6-1.2
	Rated Torque(N.m)	70
	Rated Rotate Speed (r/min)	240
	Idle Propelling Speed (mm/s)	500
	Rated Output Power (kW)	1.7
	Idle Rotary Speed (r/min)	780
	Starting Torque (N.m)	100
	Stall Torque (N.m)	110
	Max. Loading Torque (N.m)	95
	Max. Height(mm)	3055
	Min. Height(mm)	1255
	Air Consumption (m3/min)	2.5
	Noise (dB(A))	≤95
	Weight (kg)	35
	Chuck Size (mm)	B19(Standard), B22(Optional)
Hexagonal Drilling Rod	Specification (mm)	B19, B22
	Screw Thread Size	M14x1.5 Rectangular Thread 16M16x2 Rectangular Thread 18
	Length	Customized As Per Requirements
Drilling Bits	Specification(mm)	Φ27,Φ28,Φ30,Φ32,Φ38,Φ42,Φ44
	Screw Thread Size	M14x1.5 M16x2

Certifications

Packaging & Shipping

Company Profile

Jikai(Heibei) Mechatronics Technology Co.,Ltd.(Stock code:002691),located in No.418 XiangJiang Road,National New Hi-Tech Industrial Development Zone,is the national key new high-tech enterprise,covering over research,production,sales and after-sale service. We are the professional supplier and servicer for mining equipment.Our company is a national-level innovation pilot enterprise with strong research and development capabilities.We provide customers with reliable and trustworthy products under scientific and strict quality assurance.Our company has been certificated by ISO9001,and the products have got the certification of IECEX and European community CE Authentication.Motivated by the concept of "All for clients'satisfaction",we offer after sale service to equipment failures in any time and any condition.

Workshop

Exhibition photos

FAQ

Q:How about your price?
A:If you need a large amount,we can apply a favorable pirce for you.

Q:How about the delivery time.
A:Normally the delivery time is 30 days.
Q:Can you provide training for operating the machine?
A:Yes.We can provide training in our factory or at your site.
Q:What's your warranty time?
A:12 months.
Q:Do you have after-sales service?
A:Yes, we provide you with professional technical guidance. If you need, we can send our engineers to your workplace and provide training for your employees.
