Forged Tee

Basic Info.

Model NO.	HJHYG1-17
Transport Package	Carton/Wooden Case
Specification	70*44*22mm
Trademark	Hongji
Origin	China
HS Code	73072900
Production Capacity	60000pics/Yr

Product Description

Name	Forging Reducing Tee-Type Tube Union with Dual Ferrules
Model	HJHYG1-17	Volume Size	70*44*22mm
Type	Unions	Net Weight	0.200kg(¢14-¢18-¢14)
Body Material	304, 316L, 321, etc.	Manufacturing Capacity	6000/Month
Type of Connection	Dual Ferrules	Warranty	1 year
Manufacturing	Forging and CNC	Norms	ISO/GB/JB/DIN
Application	Nontoxic Liquid or Gas, Steam, Oil	Test Norms	API 598/ GBT-13927-2008
Pressure Range	0-16MPa /0-2320psi /0-160bar	Certificate	ISO/TUV
Temperature Range	-10-150ºC /14-302ºF
Size Range	(¢12-¢14)-(¢8-¢10)-(¢12-¢14)
Thread	BSPP BSPT NPT
		Anhui Hongji Instruments & Valves Manufacturing Co., Ltd.

Model HJHYG1-17	Size(mm)
	L1	L2	I1	I2	D1	D2
¢12-¢8Dual Ferrules-¢12	64	32	17	15	12	8
¢14-¢8-¢14	66	32	17	15	14	8
¢14-¢10-¢14	66	33	17	15	14	10

Customizable services such as CAD design is provided.

100% tested before shipping.

Branding sales or OEM/ODM is provided.

Real-time plant audit provided.

Price negotiable on significant volume.
